Place of Origin: | China |
---|---|
Brand Name: | Relight |
Certification: | CE & ROHS |
Minimum Order Quantity: | 500pcs |
Price: | Negotiation |
Packaging Details: | Regular Packing or Customized Packing |
Delivery Time: | 7-10 Working Days |
Payment Terms: | T/T, Western Union, |
Supply Ability: | 200000pcs/Month |
Viewing Angle(°): | 120 | Power: | 2.5W±10% |
---|---|---|---|
Type: | LED Modules | Color Rendering Index(ra): | 80,85,70,75 |
Luminous Flux(lm): | 20-22lm,110lm,180~220Lm /230~270Lm | Operating Temperature(℃): | -20 - 45 |
Storage Temperature(℃): | -40 - 60 | Warranty: | 3 Years |
Led Type: | SMD5050RGB,SMD5050/5630/5730/3030/2835/COB | Ip Grade: | IP65 |
High Light: | 110lm/W Led Lighting Module,SMD5630 Led Lighting Module,40W Ceiling Lighting Led Module |
Item
|
Power/W
|
Voltage/v
|
PF
|
Size/mm
|
CRI
|
Flux/lm
|
CCT
|
Efficiency-lm/W
|
RL-TOD5472AF0040HV830
|
40
|
220
|
>0.95
|
54*72
|
80
|
4000
|
3000
|
100
|
RL-TOD5472AF0040HV-860
|
40
|
220
|
>0.95
|
54*72
|
80
|
4400
|
6000
|
110
|
RL-TOD5472AF0070HV-830
|
70
|
220
|
>0.95
|
54*72
|
80
|
6300
|
3000
|
90
|
RL-TOD5472AF0070HV-860
|
70
|
220
|
>0.95
|
54*72
|
80
|
7000
|
6000
|
100
|
Ordering Guide
RL
|
TOD
|
5472
|
AF
|
0
|
070
|
HV
|
8
|
60
|
COMPANY
|
Interface
|
size
|
Material
|
Shape
|
Power
|
voltage
|
CRI
|
CCT
|
RELIGHT
|
TOC: connector
|
/mm
|
Aluminum
|
O: Round
|
70W
|
HV:220
|
8:80
|
6000K
|
|
TOW: cable
|
|
F:FR4
|
F:rectangle
|
|
LV:110
|
9:90
|
|
|
TON: Pads
|
|
|
|
|
|
U:95
|
|
|
TOD: withdriver
|
|
|
|
|
|
|
|
1.High efficiency up to 110lm/W, specifically customized;
2.Quick and easy wiring & assembly with low cost;
3.High CRI even up to 98;
4.No color issue, single color support, with special spectrum;
5.Low thermal resistance, No EMI issue.
6.Alternative solutions for flood lights.
